InTel Industrial OPS PC I7 10210U 10510U 4K Display Type C Port Standard OPS MINI PC

Place of Origin Guangdong
Brand Name INGSCREEN
Certification CE CB FCC ROHS ISO9001
Model Number IS-I5G10
Minimum Order Quantity 1
Price $155-$170 /Unit
Packaging Details Carton, Wooden rack & Wooden box
Delivery Time 5 workdays
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 50000 Pcs/Per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Smart OPS PC Size 195*180*30mm
CPU I5-10210U RAM DDR4 4G
ROM 128G Cache 6MB
Max.frequency 4.2 Ghz Core 4
High Light

InTel ops pc i7

,

Industrial ops pc i7

,

Type C ops computer module

Leave a Message
Product Description

In-tel industrial OPS PC 10210U 10510U 4K display type-c port standard OPS MINI PC



The OPS system connects to interactive flat panel display through a single 80-pin port, which provides power and all communications between OPS and the display. A single connection that meets conditions such as computer power, video and audio display, USB for touch input on interactive displays and independent power input for independent use.The OPS system makes the deployment of many different large-scale display solutions much easier than usual. The solution is easy to do so that installation and setup is much faster. It reduces the need for cables and trunking, which saves purchase and service costs. OPS system can be used for multiple purposes such as classroom or lecture hall study, business introduction, group video conference and any collaborative workspace.



Mini PC Model OPS-10U 180*120*30mm European Standards 80pin
Processor Support Comet Lake 10th Generation : I3 10110U,I5 10210U,I7 10510U
Network Card

1*RJ45 lan port, Realtek 8111H Gigabit Ethernet chip, supports Wake-on-LAN and PXE diskless boot function

MINI-PCIE port,default support WIFI/3G/4G/Blue-tooth module

CPU Brand Intel
Display Output Support
Graphics Card

HD-MI+VGA,Intel HD Graphics.4K UHD

DP optional

Multi-Graphics Card Not Support
Memory 2*DDR4 ,support 4G/8G/16G/32G/64G
Memory Channel Dual channels
I/O Interfaces 1*DC-in,1*OPS Slot,1*HD-MI,1*VGA , 2*USB3.1 , 2*USB2.0 , 1*LAN,1*AUDIO,1*ON/OFF,1*RESET,1*CMOS.1*TYPE C
Condition 100%New
Storage

Supporting these hard disks:

MSATA hard disk:8G/16G/32G/64G/120G;
SSD hard disk:8G/16G/32G/64G/120G;
Laptop hard disk:320G/500G/1TB.

Case Material Aluminium
Color Black
Case Size 180*120*30MM
Audio

Realtek ALC662/660 HD digital audio decoder, 6-channel high-fidelity audio controller

1* Line-out port ,audio output

1*MIC-IN port

1*INT_SPK pin, support 8 Ohm 5 watt amplifier speaker

1*F_AUDIO,Standard audio pin

1*SPDIF pin,Digital audio pin

Power Supply DC12V/DC19V
Expansion Slots 1*Mini-PCIE ,1*MSATA,Supporting Wall Hanging,WIFI Antenna Stick,OPS Daughter Card.
Operating System Windows7, Windows8.1, Windows10, Linux.
Working Temperature -20~60℃ at 0.7m/s air flow.
Relative Humidity 95%
