65 Inch 55 Inch Ir Multi Touch Infrared Touch Frame 2mm A Type USB

Place of Origin Guangdong
Brand Name INGSCREEN
Certification CE CB FCC ROHS ISO9001
Model Number IS-65TFP
Minimum Order Quantity 1
Price $60-$66 /Unit
Packaging Details Carton, Wooden rack & Wooden box
Delivery Time 5 workdays
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 5000 Pcs/ per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Interactive Touch Frame Size 65 Inch
Material Plastic( Aluminum Alloy Is Optional) Touch Technology IR
Points 20 Points Color Black
Port USB Response Time <20ms
Touch Accurancy ±2mm
High Light

65IN multi touch infrared touch frame

,

55IN multi touch infrared touch frame

,

55 inch ir touch frame ODM

Leave a Message
Product Description

High quality 65'' Multi touch IR Touch Frame Interactive Touch Screen Frame





We offer a wide range of IR touch frames with touch capabilities up to 32 touch points. Starting with standard sizing from 31.5”, our touch frame kits can be manufactured to fit custom aspect ratios, like 32:9 and can cater for large format applications providing touch solutions for displays up to 10m x 3m. We can provide made to measure solutions to fit existing display formats like LED modular systems, that require the same minimal, hassle free set up as our standard infrared touch overlays.



Product Name
IR Touch Frame
Size
19" 19.5" 21.5" 24" 27" 32" 43" 49" 55" 65" 70" 75" 86" or Customize
Material
Aluminum Alloy+Glass / Plastic+Glass
Color
Black
Interpolation Resolution
32767*32767
Respond Time
≤10ms
Touch Accuracy
± 2mm (over 90% Area)
Touch Input Method
Finger,Pomiter,Styplus pen or any other Opaque objects
Output Form
Coordinate Value
Touch Durability
Unlimited
Available Object Sizes for Touch
Φ5mm
Interface
A-Type USB/M
Electrical Specification
Scan Rate
200HZ
Communication Protocol
USB2.0 Full Speed
Transmission Rate
12Mbps
Power Supply Mode
USB
Supply Voltage
DC+5V+5%
Operating Current
<200mA
Software Specification
Multi touch
Win 7 Ultimate, Win7 professional, Win 7 home premium, Android
Single Touch
Win 7, win XP, Vista, Linux, Mac, Android and WinCE
Environmental Specification
Operating Temperature
-10 〜50°C
Storage Temperature
-20 〜60°C
Humidity
Operating: 10%~85%, non-condensing.
Storage: 10%~90%, non-condensing.
Firmware Upgrade
USB Upgrade: Win7, Win XP
ESD
EN 6100-4-2 2008:3 level. 4 KV contact discharge and 8 KV air discharge (The touch panel under test should be assembled with display devices.)
Features
Support 24 touch points, Detachable design, Anti-light Interference excellent, Less energy-intensive,more environment-friendly, A plug-and-play device.
